2021 UniCarriers CFU50LP
- Type
- Forklifts / High-Capacity Forklifts
- Stock#
- Q21891
- Condition
- Used
- Engine
Specifications
Additional Description
The 2021 UniCarriers Model CFU50LP is an internal combustion (IC) forklift from the Platinum II Series, specifically designed for indoor warehouse applications. It features a 5,000 lb load capacity at a 24-inch load center and utilizes cushion tires for superior maneuverability in tight spaces
Key Performance Specifications
Key Performance Specifications
- Engine: Powered by the GK25 (2.5L) electronically controlled fuel-injected engine.
- Fuel Type: Primarily Propane (LPG).
- Output: Produces approximately 62.9 HP at 2,700 rpm and 138.7 ft-lb of torque at 1,600 rpm.
- Lifting Speed: Capable of a full-load lifting speed of 129.9 fpm.
- Travel Speed: Reaches up to 10.6 mph with a full load.
- Standard Mast: Often equipped with a 3-stage (Triplex) mast providing a maximum lift height of 187 inches (approx. 15.5 ft).
- Height: The lowered mast height typically sits around 83 inches, allowing for passage through standard doorways.
- Width & Length: It has an overall width of 42.1 inches and a length to the fork face of 91.3 inches.
- Weight: The total service weight is approximately 7,940 lbs to 8,708 lbs, depending on the specific configuration.
- Operator Presence System (OPS): Automatically interrupts power and locks mast functions if the operator leaves the seat.
- Comfort: Includes a full suspension seat with lumbar support and weight adjustments to reduce fatigue.
- Maneuverability: Features a small-diameter steering wheel and hydrostatic power steering for high agility in confined areas.
- Stability: Equipped with a rubber damper mounted between the axle and frame to enhance lateral stability during turns.
